Profurl manuele rolreefsysteem Cruising C520
Gegevens
Profurl C520: Manual furling system - Cruising - Max forestay dia: 16 mm / 19 mm* - Boat length: 16,5 to 18,5 m
General description
Reliability, toughness and long-life: Profurl's Cruising range of reefing-furling systems are designed for coastal cruising, blue water cruising, or even sailing around the world. Cruising reefing-furling systems are designed to last and integrate the best of Profurl's proven technology to guarantee both your safety and your sailing pleasure.
The C520 model can be fiitted with 19 mm forestay. In that case a swageless eye is mandatory and the sail area recommanded must be respected as well as the drum capacity.
Technical description
| Name : | C520 |
| Range : | Cruising |
| Max forestay diameter : | 16 mm (5/8'') rod 60 / 19 mm* (3/4'') - rod 76 |
| Boat length : | From 16.50 to 18.50m (56ft - 65ft) |
| Standard furling length (others) : | 20 m (22 and 24m) |
| Extrusion length : | 2m (6 6') |
| Extrusion shape and colour : | Round and silver anodised |
| Clevis poin diameter (mm) : | 16/18/19/22/25/28 |
| Feeder : | Yes |
| Luff line diameter : | 6mm (15/64'') |
| Double luff groove : | Yes |
| Removable drum : | Yes |
| Furling line diameter : | 10 or 12mm (3/8'' or 1/2'') |
| Drum capacity : | Diameter of the furling line: 10mm (3/8'') 30m - Diameter of the furling line: 12mm (1/2'') 22m |
| Max LP : | Diameter of the furling line: 10mm (3/8'') 26,5m - Diameter of the furling line: 12mm (1/2'') 14,5m |
| Max genoa area : | 140 sqm |
| Standard fitting : | Closed to the deck |
| Warranty : | 10 year |
Accessory
- Opening luff rope prefeeder: option
- Swivelling attachment device: option
- Long link plates: option
- Turnbuckle cylinder: option
Reefing kit: option incl: 30m reefing line (dia 10mm)
1 stanchion block art Wichard 60125, 4 stanchion bloks art Wichard 60025
Meer informatie
| Boot lengte | 16,5 - 18,5 meter |
|---|---|
| Merk | Profurl |
| Diameter voorstag | 16/19 mm |
| Type rolreefsysteem | Hoofdzeil |
| Datasheet | Download |
| Zeiltype | Giek, Genua |
| Maximale zeiloppervlakte | 140m² |
| Bediening rolreefsysteem | Manueel |
